Maxwell Windlasses Selection Guide

Selecting the correct anchor winch (or windlass) is essential for safe, smooth, and reliable anchoring. The chart below offers a helpful starting point, but every boat is different — and understanding a few key factors will make sure your system performs exactly as you need it to.

When choosing a windlass, always take into account your boat’s size, displacement, and overall design:

• Heavier vessels or boats with higher windage naturally place more strain on the ground tackle, so they require a larger, more powerful windlass to operate efficiently.
• Light cruising sailboats, heavy trawlers, and performance yachts all have very different demands, and your anchoring system should match those real-world conditions.

Anchoring environment also plays a major role. If you regularly anchor in strong currents, deep water, rocky bottoms, or high-wind locations, you’ll want a windlass that offers higher pulling power and increased durability.

• A properly matched system ensures smoother retrieval, reduced strain on your equipment, and a safer experience on deck.

It’s also important to remember that every anchor winch system assumes you’ll be using a chain stopper, chain snubber, or mooring cleat to take the load off the windlass once the anchor is set or needs breaking loose. These components protect the windlass from unnecessary stress and extend its lifespan.

• As a general rule, the maximum pulling capacity of your windlass should be at least three times the total weight of your ground tackle—including anchor, chain, and rode. This ensures the unit can handle not only the weight itself but also additional loads caused by waves, wind, and boat movement.

By pairing your boat with the right windlass, you’ll enjoy more efficient anchor handling, reduced risk of equipment failure, and a system that’s ready for any conditions you encounter on the water.

Click for Maxwell Windlasses

Windlass Model Boat Length Overall (ft)
