Simpson Lawrence to Lewmar
These meticulously crafted artifacts from yesteryears stand as a testament to Lewmar's enduring commitment to maritime excellence.
Join us on a journey through a curated selection of these vintage treasures, each one a piece waiting to be rediscovered.
Horizon 400 (serial prefix 528)/Horizon 500 (serial prefix 529)
- Horizon 400 introduced 1999
- Discontinued around 2006
- Closest direct replacement: Pro-Sport
Horizon 600 (serial prefix 540)/Horizon 900 (serial prefix 550)
- Metal gypsy (Gypsy & gypsy/drum)
- Discontinued around 2006
- Closest direct replacements: Pro-Series 700/1000
Horizon 600FF (serial prefix 541)/Horizon 900FF (serial prefix 551)
- Metal gypsy (Gypsy & gypsy/drum)
- Discontinued around 2006
- Closest direct replacements: Pro-Series 700/1000
Horizon 1000 (serial prefix531/532) / Horizon 1500 (serial prefix 533/534)
- Metal gypsy (Gypsy & gypsy/drum)
- Discontinued around 2006
- Closest direct replacements: H2 (serial prefix 520)
Horizon Express (serial prefix 536)
- Gypsy only
- Discontinued around 2003
- Closest direct replacements: H3 (serial prefix 530)
- Sprint 400 introduced 1999, Sprint 500 from 1998
- Plastic gypsy in Sprint 400; Sprint 500 can have either plastic or metal gypsy. Gypsy only
- Closest direct replacements: V700
Sprint 600 (serial prefix 606) - V700
- Metal gypsy. Gypsy only
- Sprint 600 introduced 1999
- Closest direct replacements: V700
Sprint 900 (serial prefix 437 –GD/438- GO) aka Anchorman Sprint 900
- Metal gypsy. Gypsy & gypsy/drum
- 12v only, 1000 watt motor, Max pull 880 lbs
- Closest direct replacements: V1
Sprint 1000 (serial prefix 609 - GD/610 - GO)
- Metal gypsy. Gypsy & gypsy/drum
- Vertical motor. Spur gearbox
- Closest direct replacements: V1 - GYPSY ONLY
Sprint 1500 (serial prefix 615 -GD/616 - GO) - V2
- Gypsy & gypsy/drum
- Vertical motor. Spur gear box
- Closest direct replacements: V2
3000 (serial prefix 630 -GD/631 - GO: Sprint 3000A 632)
- Gypsy & gypsy/drum
- Vertical motor. Spur gear box series wound motor
- Closest direct replacements: V4
Sprint Atlantic (serial prefix 457 - GD/458 - GO) -> V2
- Gypsy & gypsy/drum
- Horizontal motor. Worm-gear transmission
- Introduced 1997, Only marketed in US, was superceded by Sprint 1000
- Closest direct replacements: V2
Anchorman 700/1000 (billed in 2000 catalog as 800 & 1000) (serial prefix 700 = 445/446; 1000 = 439/440) Anchorman 800 (serial prefix 435/436)
- Gypsy & gypsy/drum
- Anchorman 800 introduced 1995 to US market
- Closest direct replacements: V1
Anchorman 1200 (serial prefix 447/448)
- 4 wire motor
- Closest direct replacements: V2
Anchorman Power (serial prefix 450)
- 3 wire motor
Concept 0
- New hole for the V700 will take up all the existing holes for the installation
- Closest direct replacements: V700
Concept 1
- Deck unit can be replaced with CPX 2 deck unit
- Hole pattern and shaft hole are the same
- 3 wire motor
- Closest direct replacements: V2
Concept 2
- 3 wire motor post 1999, 2 wire motor pre-1999
- V4 only requires new wiring
- V3 requires changing deck unit
- Closest direct replacements: V3/4
Concept 3
- 4 wire motor
- Closest direct replacement: V700
- Closest direct replacements: V4
Discontinued Lewmar Windlass to Current Range
Choosing the right replacement for an older or discontinued Lewmar windlass can feel overwhelming—especially if your unit has been onboard for a decade or more. Over the years, Lewmar has retired several legacy models, including the popular Horizon, Sprint, and Simpson Lawrence series. For boat owners, this often means encountering questions like: Which windlass do I have? Is it still supported? And what modern unit will fit in its place?
Here you can find some of the obsolete windlasses that have a current replacement option MAURIPRO recommends to ensure a smooth upgrade.
Series 300
- Gypsy & gypsy/drum
- Closest direct replacement: V3
Series 3500
- Gypsy/drum
- Closest direct replacement: V3
Series 4000
- Gypsy/drum
- Closest direct replacement: V4
Series 5000
- Gypsy/drum
- Closest direct replacement: V6
Why Upgrading an Obsolete Windlass Is Worth It
Even if your old windlass still operates, replacing it with a modern model can deliver big benefits:
Improved Reliability
Newer motors are sealed, more resistant to corrosion, and built for higher duty cycles.
Better Holding and Pulling Power
Modern gypsies grip rope and chain more effectively, preventing slippage.
Enhanced Safety
Smooth operation means fewer anchor retrieval hazards, especially in rough weather.
Readily Available Parts
Service kits, switches, and motors are easy to source, unlike parts for discontinued units.
Long-term Value
A reliable windlass is a major selling point when you decide to upgrade your vessel.
How MAURIPRO Helps You Choose the Right Replacement
Upgrading a windlass can feel complex, especially when dealing with an obsolete model. MAURIPRO’s technical team supports you by:
- Confirming your current model
- Comparing specs between old and new units
- Suggesting the correct Pro-Series, ProFish, or V-Series replacement
- Verifying hole patterns and deck compatibility
- Ensuring your chain and rode match the new gypsy
- Recommending accessories like switches, breakers, and solenoids
Whether you send photos, model numbers, or mounting details, MAURIPRO can walk you through the process step-by-step.
Lewmar has discontinued several older windlass models, here you can find which ones are obsolete and their possible replacements.
Each obsolete windlass has a recommended modern replacement, simplifying upgrades and ensuring reliable performance.
Correct fit matters—motor type, wiring, and gypsy style must match to ensure a smooth and compatible windlass installation.
Find all the Lewmar Windlass options here:
Have questions? We're here to help - just a click away.
1 comment
I have a Simpson Lawrence 12V anchor windlass with a serial number that starts with 471. It is gypsy only and the motor hangs vertically. There is a socket to release the gypsy clutch but no socket for manual operation. What model of winch is this?
