DESCRIPTION
DESCRIPTION
The Lofrans Project 1500 X3 C Windlass is a robust electric anchor windlass designed for mid-sized boats, likely in the 45-60 foot range. The 1500-watt motor provides ample power for both chain and rope with its separate gypsy and capstan. Built with a focus on durability, it features a corrosion-resistant body and a manual override system for backup in case of electrical issues. The X3 C also offers the option of adding a chain counter for precise anchor rode monitoring, making it a reliable choice for confident anchoring.
Standard Equipment:
- Watertight dual-direction control box
- Two heavy duty covered footswitches
- Emergency override handle
- Rope/chain gypsy
- Neoporene deck gasket
FEATURES
FEATURES
- X3 Project 1500 Series vertical windlass.
- High-power 1700W electric motor, 12V operation.
- Features both gypsy and drum for versatility.
- Compatible with 3/8" G4 calibrated chain.
- Built for reliable and efficient anchoring.
TECHNICAL INFORMATION
TECHNICAL INFORMATION
| Description | Imperial | Metric |
|---|---|---|
| Motor Wattage | 1700 W. | |
| Description | Project 1500 Windlass, Capstan, 1700W, 12VDC, Chrome | |
| Power Rating | 2450.00 lb. | 1111.00 kg. |
| Approx. Amp Draw | 90 - 135 amp. | |
| Max Retrieval Speed | 60.00 ft/min | 19.00 m/min |
| Deck Thickness | 1 15/16 - 2 3/4 in. | 49.00 - 70.00 mm. |
| Volts | 12 V. | |
| Approximate Ship Weight | 68.00 lb. | 31.00 kg. |
