Goiot Cristal Hatch Size 44C - Cut Out: 47.6 x 47.6 cm (18 3/4 x 18 3/4 in) - Grey Acrylic / Aluminum Frame (106410)
Goiot Cristal Hatch Size 44C - Cut Out: 47.6 x 47.6 cm (18 3/4 x 18 3/4 in) - Grey Acrylic / Aluminum Frame (106410) is backordered and will ship as soon as it is back in stock.
Description
Description
The Goiot Cristal Hatch #106410 is a robust and stylish ventilation hatch that's perfect for enhancing airflow on your vessel. With its elegant design and durable construction, this hatch is an excellent choice for both small and large spaces. It combines functionality with a sleek appearance, making it a must-have for any sailing enthusiast.
Benefits
- Strong aluminium profile for enhanced durability
- One-piece aluminium casting lid for a seamless look
- Wide range of sizes for varied applications
- Friction hinges with compensating spring for easy lid positioning
- Maximum opening angle of 180°
Constructed with a sturdy grey acrylic and aluminum frame, this hatch measures 17 5/16 x 15 1/4 inches (440 x 387 mm). It's designed to withstand the tough maritime environment, providing dependable performance. Ideal for both ventilation and storage, this hatch seamlessly blends into any marine setup.
UsageThis ventilation hatch is perfect for improving airflow in cabins and other enclosed spaces on your boat. It's also a great option for use as a storage locker, offering versatility and practicality.
Our Part # GOI-106410 | Mfr. Part # 106410
Features
Features
- Integration range features a friction device, which allows the hatch to be held open in any position, up to 180°
- Supplied as standard with a gray acrylic
- Approved in areas IIa, III and IV
Technical Information
Technical Information
Description | Imperial | Metric |
---|---|---|
Weight | 12.79 lb | 5.8 kg |
Cut-out dimensions | Ã18 3/4 in | Ã476.0 mm |
Overall dimensions | Ã20 1/2 in | Ã52.0 cm |
Cut-out radius | - | - |
Acrylic thickness | 5/16 in | 8.0 mm |
Lid height | 1 3/32 in | 28.0 mm |
Frame flange | 1/2 in | 12.0 mm |
