Goiot Flush Hatch Size T70 - Cut Out: 62.7 x 62.7 cm (24 11/16 x 24 11/16 in) - Grey Acrylic / Aluminum Frame (116460)
Goiot Flush Hatch Size T70 - Cut Out: 62.7 x 62.7 cm (24 11/16 x 24 11/16 in) - Grey Acrylic / Aluminum Frame (116460) is backordered and will ship as soon as it is back in stock.
Description
Description
The Goiot Flush Hatch #116460 is crafted for those who appreciate sleek design and robust functionality on their production boats. This hatch combines a sturdy aluminum frame with grey acrylic to ensure durability without compromising on style. Its innovative design creates a seamless look on your boat's deck, marrying practicality with aesthetic appeal.
Benefits
- Thick aluminum profile frame for enhanced strength
- 15 mm grey acrylic for rigidity and style
- Telescopic stays for easy operation
- Ergonomic handles for comfortable use
- Stainless steel hinges for smooth opening
Constructed with a robust aluminum frame and 15 mm thick grey acrylic, this flush hatch measures 27 7/16 x 27 7/16 inches (697 x 697 mm), ensuring a perfect fit for your sailing needs. The use of stainless steel hinges eliminates the need for opening frames, offering a smooth finish on the deck.
Our Part # GOI-116460 | Mfr. Part # 116460
Technical Information
Technical Information
Description | Imperial | Metric |
---|---|---|
Weight | 24.25 lb | 11.0 kg |
Cut-out dimensions | 24 2/3 x 24 2/3 in | 627.0 x 627.0 mm |
Overall dimensions | 27 4/9 x 27 4/9 in | 697.0 x 697.0 mm |
Cut-out radius | 1 2/3 in | 42.5 mm |
Acrylic thickness | 19/32 in | 15.0 mm |
Lid height | 1 2/9 in | 31.0 mm |
Frame flange | 19/32 in | 15.0 mm |
