All Performa winches feature sandblasted drums optimized for halyard and sheeting applications using small-diameter, high-tech line. Self-tailing winches have narrow composite jaws to ensure superior holding power on small-diameter line. The self-tailing mechanism on the winch means that one crew member can quickly and easily trim or raise sails.
Our Part # HAR352STEP12HLM | Mfr. Part # 35.2STEP12HLM
FEATURES
FEATURES
- 12V electric power for easy winching.
- Robust aluminum build, sleek black finish.
- Two-speed functionality for versatile control.
- Designed for horizontal left-hand mounting.
- Radial drum with DFCB technology.
TECHNICAL INFORMATION
TECHNICAL INFORMATION
| Description | Imperial | Metric |
|---|---|---|
| Voltage | 12 V | 12 V |
| Max Current Draw | 100 A | 100 A |
| Max Line Pull | 1,100 lb | 500.0 kg |
| Recovery Speed | 60 ft/min | 18.3 m/min |
| Drum Dia. | 2 1/2 in | 63.5 mm |
| Overall Length | 10 1/2 in | 26.7 cm |
| Overall Width | 9 1/2 in | 24.1 cm |
| Overall Height | 7 1/2 in | 19.1 cm |
| Color | Black | Black |
| Material | Aluminum | Aluminum |
