Seldén's polyester rope for halyards, sheets and control lines. The two figures that matter when you pick a size are the breaking load and the safe working load, and the safe working load depends on how the end is finished: a knot takes more strength out of the rope than a splice does.
This is the PET 16/16 construction in 12 mm, blue. Seldén rates it at 2,700 kg breaking load, with a safe working load of 810 kg on a knotted end and 1,350 kg on a spliced end.
Buy by the foot.
Our Part # SEL611-015 | Mfr. Part # 611-015
FEATURES
FEATURES
- Model: PET 16/16.
- Sub-Type: PET 16/16.
- Diameter: 12 mm (0.47 in).
- Breaking Load: 2,700 kg (5,952.47 lb).
- SWL / knot: 810 kg (1,785.74 lb).
- SWL / splice: 1,350 kg (2,976.24 lb).
- FixType: 5-7(8).
- Color: Blue.
TECHNICAL INFORMATION
TECHNICAL INFORMATION
| Description | Imperial | Metric |
|---|---|---|
| Model | PET 16/16 | PET 16/16 |
| Sub-Type | PET 16/16 | PET 16/16 |
| Diameter | 0.47 in | 12 mm |
| Breaking Load | 5,952.47 lb | 2,700 kg |
| SWL / knot | 1,785.74 lb | 810 kg |
| SWL / splice | 2,976.24 lb | 1,350 kg |
| FixType | 5-7(8) | 5-7(8) |
| Color | Blue | Blue |
| Weight | 3.46 oz. | 98.00 g. |
| Safe Working Load | 1785.74 lb. | 810.00 kg. |
