EnsenadaFractional Sloop1972-1981

Ensenada 20 Parts

Lines here are cut for this rig

Rig
Fractional Sloop
I
20.71 ft
J
8.79 ft
P
24.93 ft
E
8.67 ft
Full specifications
Different version? Compare 1 related rigs
ModelIJPE
Ensenada 20 this page20.718.7924.938.67
Ensenada 252810.725.2510

Feet, from MAURIPRO Sailboat Data. If your mast or boom differs from every row, send us your measurements before ordering.

Line type
Grade
Compare grades

Halyards 9

  • Cruising

    Mainsail Halyard

    Diameter
    8 mm (5/16 in)
    Length
    60 ft (18.3 m)
    Hardware
    Shackle
    List Price:  $218.41 USD
    $162.00 USD

    Available to order · 5 options

  • Club Racing

    Mainsail Halyard

    Diameter
    6 mm (1/4 in)
    Length
    60 ft (18.3 m)
    Hardware
    Shackle
    List Price:  $227.59 USD
    $168.00 USD

    Available to order · 14 options

  • Grand Prix Racing

    Mainsail Halyard

    Diameter
    6 mm (1/4 in)
    Length
    60 ft (18.3 m)
    Hardware
    Shackle
    List Price:  $541.31 USD
    $401.00 USD

    Available to order · 10 options

  • Cruising

    Genoa Halyard

    Diameter
    8 mm (5/16 in)
    Length
    48 ft (14.6 m)
    Hardware
    Shackle
    List Price:  $236.08 USD
    $175.00 USD

    Available to order · 5 options

  • Club Racing

    Genoa Halyard

    Diameter
    6 mm (1/4 in)
    Length
    48 ft (14.6 m)
    Hardware
    Shackle
    List Price:  $661.01 USD
    $490.00 USD

    Available to order · 14 options

  • Grand Prix Racing

    Genoa Halyard

    Diameter
    6 mm (1/4 in)
    Length
    48 ft (14.6 m)
    Hardware
    Shackle
    List Price:  $682.66 USD
    $506.00 USD

    Available to order · 10 options

  • Cruising

    Spinnaker Halyard

    Diameter
    6 mm (1/4 in)
    Length
    51 ft (15.5 m)
    Hardware
    Shackle
    List Price:  $221.73 USD
    $164.00 USD

    Available to order · 5 options

  • Club Racing

    Spinnaker Halyard

    Diameter
    6 mm (1/4 in)
    Length
    51 ft (15.5 m)
    Hardware
    Shackle
    List Price:  $277.23 USD
    $205.00 USD

    Available to order · 14 options

  • Grand Prix Racing

    Spinnaker Halyard

    Diameter
    6 mm (1/4 in)
    Length
    51 ft (15.5 m)
    Hardware
    Shackle
    List Price:  $688.85 USD
    $511.00 USD

    Available to order · 10 options

  • View moreAll Ensenada 20 halyards & sheets

Made up to the lengths computed from the Ensenada 20's rig dimensions above. Colour and taper are chosen when you add to cart.

Sheets & guys 12

  • Cruising

    Genoa Sheet

    Diameter
    8 mm (5/16 in)
    Length
    30 ft (91 m)
    Hardware
    None listed
    $43.57 USD

    Available to order · 5 options

  • Performance Cruise

    Genoa Sheet

    Diameter
    8 mm (5/16 in)
    Length
    30 ft (9.1 m)
    Hardware
    Soft shackle
    List Price:  $152.88 USD
    $113.00 USD

    Available to order · 4 options

  • Club Racing

    Genoa Sheet

    Diameter
    6 mm (1/4 in)
    Length
    30 ft (9.1 m)
    Hardware
    Soft shackle
    List Price:  $150.48 USD
    $111.00 USD

    Available to order · 14 options

  • Grand Prix Racing

    Genoa Sheet

    Diameter
    6 mm (1/4 in)
    Length
    30 ft (9.1 m)
    Hardware
    Soft shackle
    List Price:  $164.21 USD
    $121.00 USD

    Available to order · 8 options

  • Cruising

    Asymmetrical Spinnaker Sheet

    Diameter
    6 mm (1/4 in)
    Length
    40 ft (12.2 m)
    Hardware
    Shackle
    List Price:  $201.30 USD
    $149.00 USD

    Available to order · 5 options

  • Performance Cruise

    Asymmetrical Spinnaker Sheet

    Diameter
    8 mm (5/16 in)
    Length
    40 ft (12.2 m)
    Hardware
    Shackle
    List Price:  $639.01 USD
    $474.00 USD

    Available to order · 4 options

  • Club Racing

    Asymmetrical Spinnaker Sheet

    Diameter
    6 mm (1/4 in)
    Length
    40 ft (122 m)
    Hardware
    None listed
    List Price:  $180.57 USD
    $134.00 USD

    Available to order · 14 options

  • Grand Prix Racing

    Asymmetrical Spinnaker Sheet

    Diameter
    6 mm (1/4 in)
    Length
    40 ft (122 m)
    Hardware
    None listed
    List Price:  $198.68 USD
    $147.00 USD

    Available to order · 8 options

  • Cruising

    Symmetrical Spinnaker Sheet

    Diameter
    6 mm (1/4 in)
    Length
    40 ft (12.2 m)
    Hardware
    Shackle
    List Price:  $201.30 USD
    $149.00 USD

    Available to order · 5 options

  • Performance Cruise

    Symmetrical Spinnaker Sheet

    Diameter
    8 mm (5/16 in)
    Length
    40 ft (12.2 m)
    Hardware
    Shackle
    List Price:  $250.36 USD
    $185.00 USD

    Available to order · 4 options

  • Club Racing

    Symmetrical Spinnaker Sheet

    Diameter
    6 mm (1/4 in)
    Length
    40 ft (12.2 m)
    Hardware
    Shackle
    List Price:  $686.95 USD
    $510.00 USD

    Available to order · 14 options

  • Grand Prix Racing

    Symmetrical Spinnaker Sheet

    Diameter
    6 mm (1/4 in)
    Length
    40 ft (12.2 m)
    Hardware
    Shackle
    List Price:  $705.07 USD
    $523.00 USD

    Available to order · 8 options

  • View moreAll Ensenada 20 halyards & sheets

Made up to the lengths computed from the Ensenada 20's rig dimensions above. Colour and taper are chosen when you add to cart.

Compare grades

GradeRope, as described on each productColoursTapered optionFromFilter
Cruising6 lines Cruiser XTS Polyester Double Braid Up to 5 No $43.57
Performance Cruise3 lines DX Performance SK38 with polyester cover Up to 4 No $113.00
Club Racing6 lines S Cup (Stirotec with polyester cover) Up to 7 Yes $111.00
Grand Prix Racing6 lines DX Cup Dyneema SK78 core with polyester coverTN Racing - Stirotex core / Technora Polyester cover Up to 5 Yes $121.00

Rope names are quoted from each product's own description; prices are the lowest option for the Ensenada 20. Not sure which grade suits your sailing? Ask us.

Blocks 1

Mainsail covers 2

Parts marked "Sized for this boat" are chosen from the manufacturers' sizing guides (Harken, Forespar, Schaefer) using this boat's published dimensions. Check your boat's equipment before ordering.

Specifications

BuilderEnsenada
DesignerLyle C. Hess
Years built1972-1981
RigFractional Sloop
HullSwing Keel
ConstructionSwing Keel
Length overall20 ft 6.1 m
Waterline length17.5 ft 5.3 m
Beam7.1 ft 2.16 m
Draft1.8 ft 0.55 m
Displacement1,600 lb 726 kg
Ballast550 lb 249 kg
I · foretriangle height20.71 ft 6.31 m
J · foretriangle base8.79 ft 2.68 m
P · mainsail luff24.93 ft 7.6 m
E · mainsail foot8.67 ft 2.64 m
Forestay length8.8 ft 2.7 m
100% jib area91 sq ft 8.5 m²
Mainsail area116.7 sq ft 10.8 m²
Jib + mainsail area207.7 sq ft 19.3 m²
Cruising spinnaker area154.7 sq ft 14.5 m²
I 20.7 J 8.8 E 8.7 P 24.9
Sail plan drawn to scale from the rig dimensions above, in feet. Hull and keel are schematic.

Source: MAURIPRO Sailboat Data, updated 2026-07-01. Always confirm against your own boat.

More for the Ensenada 20

Other Ensenada models

Questions

What Ensenada 20 parts does MAURIPRO carry?

The Ensenada 20 page lists halyards and sheets made up to this boat's rig lengths, mainsail covers, sails, winches, blocks, travelers, genoa cars, boom vangs and spinnaker poles sized with manufacturer guides where the boat size allows. Prices and availability shown are live from our catalogue.

How do I know a part fits my Ensenada 20?

Halyards and sheets are made up to lengths computed from the Ensenada 20's published rig dimensions (I, J, P, E). Other parts are matched with manufacturer sizing guides and are labelled as sized for this boat. Fit can still depend on your boat's year, builder and rig, so check the product details or ask our technical team before you order.

Where can I find the Ensenada 20 rig dimensions?

Our Ensenada 20 Sailboat Data page lists the rig dimensions (I, J, P, E) and other published data we hold for this boat. Figures come from a sailboat database and may differ from your boat as built.
