Selden Furlex 104S–404S Spare Screw Kit — Spare Parts List

Spare Screw Kit Furlex 104S – 404S

Where used Furlex 104 Furlex 204 Furlex 304 Furlex 404
1. Adaptor A 5x16 (2) A 5x25 (2) A 6x30 (2) A 8x40 (2)
2. Top guard B 4.2x9.5 (2) B 4.8x9.5 (2) B 4.8x9.5 (2) B 4.8x13 (4)
3. Sail feeder – A 4x12 (1) A 4x12 (1) A 5x16
4. Line guide lower A 5x20 (1) A 6x25 (1) A 8x25 (1) A 8x40 (1)
5. Line guide upper A 4x16 (2*) A 5x20 (2*) A 5x20 (2*) A 6x25 (2*)
6. Brims A 4x10 (4*) A 5x16 (4*) A 5x16 (4*) A 6x20 (4*)
7. Furling line A 4x12 (1**) B 4.8x16 (2) B 5.5x19 (2) B 5.5x25 (2)
8. Drum hub C 3.6x12 (4) C 4.6x20 (4) C 5.3x20 (4) C 5.3x20 (4)

Dimension Ø x L in mm, quantity in brackets. A = metric coarse thread, B = ST (self-tapping), C = RX-Plastite. * Screws including retaining washer. ** Including washer. No quantity is printed for the 404 sail-feeder screw.

Selden Furlex 104S-404S spare screw kit: screw positions 1-8 and screw types
