Vetus Electrical Toilets & Waste Water — Spare Parts Guides

This manual is split into 2 pages: Part 1 → · Part 2

Saniprocessor and Grey Water Discharge

Saniprocessor SAPRO12 / SAPRO24 / SAPRO110 / SAPRO220

Part SAPRO12 SAPRO24 SAPRO110 SAPRO220
Case SANI001 Ask us to source it → SANI001 Ask us to source it → SANI001 Ask us to source it → SANI001 Ask us to source it →
Cover SANI002 Ask us to source it → SANI002 Ask us to source it → SANI002 Ask us to source it → SANI002 Ask us to source it →
Cover gasket SANI003 Ask us to source it → SANI003 Ask us to source it → SANI003 Ask us to source it → SANI003 Ask us to source it →
Grille SANI006 Ask us to source it → SANI006 Ask us to source it → SANI006 Ask us to source it → SANI006 Ask us to source it →
Blade complete SANI007 Ask us to source it → SANI007 Ask us to source it → SANI007 Ask us to source it → SANI007 Ask us to source it →
Lower discharge pipe SANI008 Ask us to source it → SANI008 Ask us to source it → SANI008 Ask us to source it → SANI008 Ask us to source it →
Impeller housing SANI009 Ask us to source it → SANI009 Ask us to source it → SANI009 Ask us to source it → SANI009 Ask us to source it →
Membrane SANI012 Ask us to source it → SANI012 Ask us to source it → SANI012 Ask us to source it → SANI012 Ask us to source it →
Micro switch SANI013 Ask us to source it → SANI013 Ask us to source it → SANI013 Ask us to source it → SANI013 Ask us to source it →
Pan gasket SANI028 Ask us to source it → SANI028 Ask us to source it → SANI028 Ask us to source it → SANI028 Ask us to source it →
Motor SANI010 Ask us to source it → SANI005 Ask us to source it → SANI014 Ask us to source it → SANI004 Ask us to source it →
Drainage kneepiece WC004 Ask us to source it → WC004 Ask us to source it → WC004 Ask us to source it → WC004 Ask us to source it →
Floatunit 12V SANI030 Ask us to source it → x x x
Floatunit 24V x SANI031 Ask us to source it → x x
Relay pam 24V x SANO029 Ask us to source it → x x

Grey water discharge system GWDS

Part GWDS12 GWDS24 GWDS110 GWDS220
Set mounting + conn. material GWDSSET Ask us to source it → GWDSSET Ask us to source it → GWDSSET Ask us to source it → GWDSSET Ask us to source it →
One way valve GWDS01 Ask us to source it → GWDS01 Ask us to source it → GWDS01 Ask us to source it → GWDS01 Ask us to source it →

Waste Water Tanks

Rigid tanks BTANK..C (incl. connectors, excl. filling nipple)

Part BTANK25C BTANK40C BTANK60C BTANK80C
Inspection cover WW09 Ask us to source it → WW03 Ask us to source it → WW03 Ask us to source it → WW03 Ask us to source it →
Extraction pipe l-780 mm 38 mm bend WTS78038B View product → WTS78038B View product → WTS78038B View product → WTS78038B View product →
Wrench FTSL Ask us to source it → FTSL Ask us to source it → FTSL Ask us to source it → FTSL Ask us to source it →

Rigid tanks, bulkhead mounted

Part WW25WH WW25W WW60W WW80W
Inspection cover WW09 Ask us to source it → WW09 Ask us to source it → WW03 Ask us to source it → WW03 Ask us to source it →
Hose conn. 38 mm bent RT38B View product → RT38B View product → RT38B View product → RT38B View product →
Hose conn. 19 mm bent RT19B View product → RT19B View product → RT19B View product → RT19B View product →
Extraction pipe l-780 mm 38 mm bend WTS78038B View product → WTS78038B View product → WTS78038B View product → WTS78038B View product →
Wrench FTSL Ask us to source it → FTSL Ask us to source it → FTSL Ask us to source it → FTSL Ask us to source it →

Rigid tanks complete WWS4212B, WWS4224B, WWS6112B, WWS6124B, WWS8812B, WWS8824B, WWS12012B, WWS12024B

Part Code (all eight)
Inspection cover WW03 Ask us to source it →
Hose conn. 19 mm bent RT19B View product →
Extraction pipe l-780 mm 38 mm bent WTS78038B View product →
Wrench FTSL Ask us to source it →
Ultrasonic level sensor 12/24V SENSORA View product →
Waste pump EMP14012B (12 V systems) / EMP14024B (24 V systems) View product →
Spare gasket set TGSET Ask us to source it →

All purpose tank APT100

Part Code
Viton gasket ILTCON18 Ask us to source it →

Flexible tanks for waste water

Part TANKV55 TANKV70 TANKV100 TANKV160
Hose connection 16 mm bent FT16B View product → FT16B View product → FT16B View product → FT16B View product →
Hose connection 38 mm bent FT38B View product → FT38B View product → FT38B View product → FT38B View product →
Wrench FTSL Ask us to source it → FTSL Ask us to source it → FTSL Ask us to source it → FTSL Ask us to source it →
Repairset for flexible tank REPSETOT View product → REPSETOT View product → REPSETOT View product → REPSETOT View product →

No-Smell Filters, Sensors, Panel and Pumps

No-smell filters

Part NSF16S NSF16 NSF19 NSF25 NSF38
Cover + O-ring green NSF02S Ask us to source it → NSF02 Ask us to source it → NSF02 Ask us to source it → NSF02 Ask us to source it → NSF02 Ask us to source it →
Filter element NSF16FES View product → NSF16FE View product → NSF16FE View product → NSF16FE View product → NSF16FE View product →
NSF canister NSFCANS Ask us to source it → NSFCAN Ask us to source it → NSFCAN Ask us to source it → NSFCAN Ask us to source it → NSFCAN Ask us to source it →
Set o-ring (5x) FTR14002 Ask us to source it → FTR3302 View product → FTR3302 View product → FTR3302 View product → FTR3302 View product →
Mounting bracket set MBSET03 Ask us to source it → MBSET05 View product → MBSET05 View product → MBSET05 View product → MBSET05 View product →
Unit Part Code
Wastewater tank sensor WWSENSORA Gasket blind flange ST56 Ask us to source it →
Wastewater control panel WWCP Set conn. plugs (5 + 8 pole) SETWWCP Ask us to source it →

Wastewater pumps EMP133 / EMP134 (since 2006 / 2009)

Part EMP13312 EMP13324 EMP13412 EMP13424
Motor x SET0119 Ask us to source it → x SET0119 Ask us to source it →
Valves EMP024 = SETEMPB1 Ask us to source it → EMP024 = SETEMPB1 Ask us to source it → EMP024 = SETEMPB1 Ask us to source it → EMP024 = SETEMPB1 Ask us to source it →
Set membrane, valves, O-ring EMP025 = SETEMPB2 Ask us to source it → EMP025 = SETEMPB2 Ask us to source it → EMP025 = SETEMPB2 Ask us to source it → EMP025 = SETEMPB2 Ask us to source it →
Hose connection IN EMP026 Ask us to source it → EMP026 Ask us to source it → EMP026 Ask us to source it → EMP026 Ask us to source it →
Hose connection OUT EMP027 Ask us to source it → EMP027 Ask us to source it → EMP027 Ask us to source it → EMP027 Ask us to source it →
Angled hose pilar EXIT EMP028 Ask us to source it → EMP028 Ask us to source it → EMP028 Ask us to source it → EMP028 Ask us to source it →

Wastewater pumps EMP140 (since 2010) / EMP140B (since 2014)

Part EMP14012 EMP14024 EMP14012B EMP14024B
Valves SETEMPB1 Ask us to source it → SETEMPB1 Ask us to source it → SETEMPB1 Ask us to source it → SETEMPB1 Ask us to source it →
Set membrane, valves, O-ring SETEMPB2 Ask us to source it → SETEMPB2 Ask us to source it → SETEMPB2 Ask us to source it → SETEMPB2 Ask us to source it →
Set hose connection + valves SETEMP140B Ask us to source it → SETEMP140B Ask us to source it → SETEMP140B Ask us to source it → SETEMP140B Ask us to source it →

VRF56A, BTKIT, Inspection Lids, EIP12, ASD38H

Unit Part Code
VRF56A vacuum operated relief valve Spare gasket set TGSET Ask us to source it →
VRF56A Wrench FTSL Ask us to source it →
BTKIT connection kit wastewater tank Wrench FTSL Ask us to source it →
BTKIT Inspection lid WTK02 View product →
BTKIT Plastic counter flange WTK21 Ask us to source it →
BTKIT Foam seal food quality WTK05 Ask us to source it →
BTKIT O-ring 108x3 mm 7sh WTK002 Ask us to source it →
Inspection lid ILT120F / ILT120PH / ILT120PL (Kit) silicone expansion rubber ILTSET1 / VP000068 / VP000069 Ask us to source it →
ILT120F / ILT120PH / ILT120PL Cover + nut + gasket ILTSET2 Ask us to source it →
ILT120F / ILT120PH / ILT120PL Viton gasket ILTCON18 Ask us to source it →
ILTCONW connection kit wastewater Set hose pilars 8 mm G1/4 VP000131 Ask us to source it →
ILTCONW Set hose pilars 10 mm G1/4 VP000132 Ask us to source it →
ILTCONW Set hose pilars 13 mm G1/4 VP000016 Ask us to source it →
ILTCONW Set hose pilars 16 mm G1/4 VP000133 Ask us to source it →
ILTCONW Hose barb G1-1/4 38 mm elbow ILTCON90 View product →
ILTCONW Gasket set for ILTCONW VP000015 Ask us to source it →
ILTCONW VETUS lashing straps 2x 3x25 mm VTSTRAP Ask us to source it →
ILTCONW Hole saw 159 mm VSAW Ask us to source it →
ILTCONW Expansion rubber Viton high brown ILTVITH Ask us to source it →
ILTCONW Expansion rubber Viton low brown ILTVITL Ask us to source it →
EIP12 electric impeller pump 12V Servicekit (impeller) SETEIP12 Ask us to source it →
ASD38H anti syphon device (38 mm) with hose Set valves ASDVS View product →
ASD38H O-ring 23x2,5 mm AV002 Ask us to source it →
ASD38H Wing nut ASD004 Ask us to source it →

Need a part that isn't listed? Ask us to source it and quote the part number from the PDF.
