DESCRIPTION

The PBB80 Single Block with Shackle Adaptor is designed to fit deck ring/T-base shafts of other mast brands Consequently, this block is designed to route a halyard from the mast and back to the cockpit. It features an ø80 mm glass fibre reinforced sheave with polymer bushing, stainless steel strap for durability, glass fiber reinforced composite cheeks to prevent jamming and a practical switch from swiveling to fixed shackle

FEATURES

  • Safe working Load: 2000 kg Breaking Load: 4000 kg Max line size: 16 mm.

TECHNICAL INFORMATION


DescriptionImperialMetric
Safe Working Load4,409.24 lb2,000 kg
Breaking Load8,818.48 lb4,000 kg
Max Line0.63 in16 mm
Weight1.09 lb.495.00 g.
Max Line Size0.63 in.16.00 mm.

KNOWLEDGE BASE

Selden Block Adaptors — Selection GuidePick the Selden block adaptor that puts a PBB60, PBB70 or PBB80 plain bearing block on a deck ring or mast base shaft.View Selection Guide →
