Blue Sea 2356 Water Resistant BusBar - 100 Amp w/Cover

SKU: blu-2356  |  Manuf. Code: 2356
$55.55 USD
Chat with our Tech Team Questions? Chat with our Tech Team
Backed by MAURIPRO Support Backed by MAURIPRO Support.
Simple 30-Day Returns Simple 30-Day Returns.
Simple 30-Day Returns

We offer returns within 30 days of delivery for your peace of mind.

  • 0–15 days: Free returns or exchanges
  • 16–30 days: Returns accepted with a 20% restocking fee
  • Returns after 30 days are not accepted.
  • Request a Return Authorization (RA#) prior to shipping.
  • Return shipping is the customer’s responsibility.
Price Match Guarantee Price Match Guarantee
Our Best Price Guarantee
  • We Price Match against authorized dealers only, based on the total order cost (product + shipping).
  • No auction sites
  • No unauthorized sellers
  • Item must be identical, new, and in stock

Found it cheaper? Chat with us to request a Price Match.

DESCRIPTION

2356 Water Resistant BusBar - 100 Amp with Cover

Provides secure water-resistant bussing for harsh environments. The single side nesting design allows for wire entry from one side to maximize space.

Features:

  • Water-resistant design with standard ring or fork type terminals allows for simple wiring with standard tools.
  • Accepts a wide range of wire sizes
  • Includes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used
  • Nests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
  • Ideal for positive distribution and for the collection of negative or AC ground circuits
  • Insulating cover meets ABYC/USCG insulation requirements
  • Tin-plated copper busses and fuse clips
  • Includes four write-on circuit labels
  • Small format standard and custom labels available

Specifications:

  • Cover: Yes
  • Maximum Voltage: 300V AC/48V DC
  • Continuous Rating: 100A AC/100A DC
  • Bus Material: Tin-Plated Copper C11000
  • Mounting Holes: Accepts 1/4" (6mm) Screws
  • Terminal Screw: 4 x #8-32
  • Terminal Stud: 1 x #10-32
  • Wire Size: (1) 8 AWG to 4 AWG - Input/(4) 16 AWG to 10 AWG - Load

Mfr. Part # 2356

FEATURES

  • Water-resistant design with standard ring or fork type terminals allows for simple wiring with standard tools.
  • Accepts a wide range of wire sizes
  • Includes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used
  • Nests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
  • Ideal for positive distribution and for the collection of negative or AC ground circuits
  • Insulating cover meets ABYC/USCG insulation requirements
  • Tin-plated copper busses and fuse clips

TECHNICAL INFORMATION

SpecificationValue
ManufacturerBlue Sea Systems
Manufacturer part number2356
CoverYes
Maximum Voltage300V AC/48V DC
Continuous Rating100A AC/100A DC
Bus MaterialTin-Plated Copper C11000
Mounting HolesAccepts 1/4" (6mm) Screws
Terminal Screw4 x #8-32
Terminal Stud1 x #10-32
Wire Size(1) 8 AWG to 4 AWG - Input/(4) 16 AWG to 10 AWG - Load
Supplier application or construction detailIncludes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used
Supplier technical detailIncludes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used
Supplier technical detailNests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
Supplier application or construction detailIncludes four write-on circuit labels
Supplier technical detailIncludes four write-on circuit labels
Supplier technical detailMaximum Voltage: 300V AC/48V DC
Supplier technical detailContinuous Rating: 100A AC/100A DC
Supplier technical detailMounting Holes: Accepts 1/4" (6mm) Screws
Supplier technical detailWire Size: (1) 8 AWG to 4 AWG - Input/(4) 16 AWG to 10 AWG - Load
Product-name configuration100 Amp w/Cover
