The BBB40 Double Block features two 40 mm sheaves, designed for dynamic applications under medium loads. The stainless eye is fixed and allows for shackle- or line attachments.
Stainless steel ball bearings ensure smooth, low-friction operation, while glass fiber reinforced cheeks provide strength and durability. Ideal for moderate and dynamic loads with minimal friction.
Safe working Load: 500 kg
Breaking Load: 1000 kg
Max line size: 10 mm
TECHNICAL INFORMATION
TECHNICAL INFORMATION
| Description | Imperial | Metric |
|---|---|---|
| Weight | 9.45 oz. | 268.00 g. |
| Safe Working Load | 1102.31 lb. | 500.00 kg. |
| Breaking Load | 2204.62 lb. | 1000.00 kg. |
| Max Line Size | 0.39 in. | 10.00 mm. |
