DESCRIPTION

The BBB60 Double Block features two 60 mm sheaves optimized for high dynamic loads.

A plastic washer acts as a swivel lock between the block body and shackle, allowing the shackle to be fixed at either 0° or 90°.

Glass fiber reinforced cheeks and Delrin ball bearings offer smooth, low-friction performance, making this block ideal for sheets and control lines.

Safe working Load: 700 kg
Breaking Load: 1400 kg
Max line size: 10 mm

TECHNICAL INFORMATION


DescriptionImperialMetric
Weight7.97 oz.226.00 g.
Safe Working Load1543.23 lb.700.00 kg.
Breaking Load3086.47 lb.1400.00 kg.
Max Line Size0.39 in.10.00 mm.
