DESCRIPTION

The Valley Open Cleat in Aluminium is designed for handling lines between 1-6 mm, offering excellent durability under higher load conditions. The aluminium construction prevents rope burn, making it ideal for more demanding tasks. The cleat can be used with a tapered pad (sold separately) to adjust the angle for better rope alignment. The rope drops easily into the cleat's teeth, providing a secure lock that can be quickly released. This versatile cleat can be mounted on both flat and curved surfaces using rivets, countersunk screws or bolts.

Max line size: 6 mm
Min line size: 1 mm
Hole spacing: 36 mm
Mounting: 2xM4
Weight: 16 g

TECHNICAL INFORMATION


DescriptionImperialMetric
Weight0.78 oz.22.00 g.
Max Line Size0.24 in.6.00 mm.
