Selden Turnbuckle - Bronze Body, Stainless Terminals, 3/4", ø10 mm Swage Terminal/Fork, ø19 mm Clevis Pin

SKU: SEL174-327-07  |  Manuf. Code: 174-327-07
List Price:  $457.00 USD
$420.00 USD
You save $37 off List Price.
Chat with our Tech Team Questions? Chat with our Tech Team
Backed by MAURIPRO Support Backed by MAURIPRO Support.
Simple 30-Day Returns Simple 30-Day Returns.
Simple 30-Day Returns

We offer returns within 30 days of delivery for your peace of mind.

  • 0–15 days: Free returns or exchanges
  • 16–30 days: Returns accepted with a 20% restocking fee
  • Returns after 30 days are not accepted.
  • Request a Return Authorization (RA#) prior to shipping.
  • Return shipping is the customer’s responsibility.
Price Match Guarantee Price Match Guarantee
Our Best Price Guarantee
  • We Price Match against authorized dealers only, based on the total order cost (product + shipping).
  • No auction sites
  • No unauthorized sellers
  • Item must be identical, new, and in stock

Found it cheaper? Chat with us to request a Price Match.

DESCRIPTION

Wire diam: 10 mm Thread size: 3/4" Clevis pin Ø: 19.00 mm L-MIN: 360 mm L-MAX: 568 mm W: 22.00 mm H: 32.00 mm X: 39 mm Breaking Load: 12500 kg

FEATURES

  • Wire diam: 10 mm (0.39 in).
  • Thread size: 3/4".
  • Clevis pin Ø: 19 mm (0.75 in).
  • L MIN: 360 mm (14.17 in).
  • L MAX: 568 mm (22.36 in).
  • W: 22 mm (0.87 in).
  • H: 32 mm (1.26 in).
  • X: 39 mm (1.54 in).

TECHNICAL INFORMATION

DescriptionImperialMetric
Wire diam0.39 in10 mm
Thread size3/4"3/4"
Clevis pin Ø0.75 in19 mm
L MIN14.17 in360 mm
L MAX22.36 in568 mm
W0.87 in22 mm
H1.26 in32 mm
X1.54 in39 mm
Breaking Load27,557.75 lb12,500 kg
Weight4.06 lb.1.84 kg.
Clevis Pin0.75 in.19.00 mm.
Wire Diameter0.39 in.10.00 mm.
L-MIN14.17 in.360.00 mm.
L-MAX22.36 in.568.00 mm.
