Tacktick Wireless Micronet Race Master

Yes, a Raymarine Evolution autopilot steers without a chartplotter: Raymarine's installation manual lists the essential parts as an EV-1 sensor core, an ACU actuator control unit, a drive unit suited to your steering, a SeaTalkng backbone and a compatible controller, and the p70s or p70Rs control head is that controller. The chartplotter is only an optional second way to operate the pilot, and a source of route data for Track mode.

Raymarine autopilot without a chartplotter at a glance

Product Role in the system Key fact
Raymarine EV-200 Sail Linear Drive Evolution Complete Autopilot System Complete pack for mechanically steered sailboats EV-1 sensor core, p70s control head, ACU-200 and a Type 1 12 V linear drive; Raymarine rates it for boats up to 11,000 kg (24,000 lb) displacement
Raymarine Evolution EV-1 Sensor Core Heading and motion sensor with the autopilot processor 9-axis sensor, dynamic accuracy to within 2 degrees
Raymarine P70s Autopilot Controller Push-button control head Auto, Standby, Pattern, Track, Wind Vane modes
Raymarine P70Rs Autopilot Controller with Rotary Knob Control head with rotary knob Rotary knob; Power Steer mode
Raymarine ACU-200 Actuator Control Unit Drive power and control Type 1 hydraulic, linear and rotary mechanical drives
Raymarine EV-150 Evolution Autopilot Corepack (without Drive) Core pack for hydraulic steering p70Rs, EV-1, ACU-150 and cable kit; no drive pump included

Does a Raymarine autopilot need a chartplotter?

No. The autopilot runs on its own SeaTalkng network of sensor core, actuator control unit, drive and control head. Raymarine's manual says a SeaTalkng autopilot controller is required to operate the system, and it lists the p70s and p70Rs among the compatible controllers. You can also operate the system from a compatible Raymarine multifunction display, but that is an option, not a requirement.

Raymarine EV-200 Sail Linear Drive Evolution Complete Autopilot System
Raymarine EV-200 Sail Linear Drive Evolution Complete Autopilot System

What do you need instead of a chartplotter?

You need the essential parts below, and Raymarine recommends three more inputs for the best steering. The manual lists these as essential: a compatible controller, a drive unit appropriate for your vessel, EV-1 and ACU, an ACU power cable (not supplied), and a SeaTalkng backbone. Recommended: a rudder angle reference sensor, a speed data source (a GNSS receiver giving speed over ground at minimum, ideally a speed sensor) and, on a sailboat, a wind transducer on the SeaTalkng backbone. A position data source is optional and is only used when following routes.

What does the EV-1 sensor core do?

The EV-1 is the heading source of the whole system: a 9-axis sensor that monitors heading, pitch, roll and yaw so the pilot adapts as sea conditions change. Raymarine quotes dynamic accuracy to within 2 degrees, and the sealed housing mounts above or below deck to IPX6 and IPX7 standards. It combines the sensors with the Evolution autopilot processor in one housing and connects by a single SeaTalkng cable to the control head and the ACU.

Raymarine Evolution EV-1 Sensor Core
Raymarine Evolution EV-1 Sensor Core

Should you choose the p70s or the p70Rs control head?

Choose the p70s if you want push-button control and the p70Rs if you want a rotary knob. Both are SeaTalkng/NMEA 2000 control heads with a 160 degree viewing angle, an anti-reflective coating and a start-up wizard. The p70Rs adds a rotary control knob, and Raymarine describes its Power Steer mode, which lets you use the knob like a miniature steering wheel, as exclusive to the p70Rs. The p70Rs suits auxiliary steering stations, flybridges and wing control stations.

Raymarine P70Rs Autopilot Controller with Rotary Knob
Raymarine P70Rs Autopilot Controller with Rotary Knob

Which ACU fits your steering system?

The ACU has to match your drive. The ACU-200 controls Type 1 hydraulic drives and linear and rotary mechanical drives. The ACU-150 powers and controls a Raymarine Type 1 hydraulic drive unit (M81120), works on 12 V DC systems only, and needs the EV-1, the Evolution cable kit and a p70s or p70Rs to make a complete system. For drive types, see How to Choose an Autopilot Drive for Your Steering System.

Which autopilot modes need more than the EV-1?

Wind Vane and Track modes need outside data. Wind Vane mode needs wind angle data from a wind transducer on the SeaTalkng backbone, and the pilot shows a NO WIND DATA alarm if none arrives for 32 seconds. Track mode follows routes from your GPS or chartplotter, so it needs navigation data. Raymarine also states the pilot does not require speed data to operate, but speed data improves performance in Auto mode.

Which Raymarine autopilot pack should you choose?

Frequently asked questions

Does the Raymarine EV sensor core require a chartplotter to function?

No. The EV-1 supplies heading, pitch, roll and yaw data over SeaTalkng to the control head and the ACU, so the pilot steers without a chartplotter.

What is SeaTalkng in Raymarine autopilots?

SeaTalkng is Raymarine's backbone network. A single cable carries power and data between the EV-1, the ACU and the control head, and it connects to other SeaTalkng and NMEA 2000 devices.

Can the p70s Autopilot Controller work without GPS or a chartplotter?

Yes in Auto mode. The p70s is a SeaTalkng control head, and Raymarine says the pilot does not need speed data to operate. Track mode needs navigation data from a GPS or chartplotter, and Wind Vane mode needs a wind transducer.

What does the rotary knob on the p70Rs do?

It gives you Power Steer mode, which lets you use the knob like a miniature steering wheel. Raymarine describes Power Steer as exclusive to the p70Rs.

Are Raymarine autopilots compatible with different steering systems?

Yes, but you must pick the ACU and drive that fit your steering. The ACU-200 controls Type 1 hydraulic drives and linear and rotary mechanical drives, and the ACU-150 controls the Type 1 hydraulic drive unit on 12 V systems.

What do you still need to buy for a chartplotter-free system?

Beyond the sensor core, ACU and control head, you need a drive unit for your steering, an ACU power cable (not supplied) and a SeaTalkng backbone. A rudder reference sensor, a speed source and, on a sailboat, a wind transducer are recommended.
