Two-Speed Winch Parts

No. 16 two-speed winch (PDF page 5)

Part no.	Item	Description
B2075	1	Circlip	Ask us to source it →
15000478	2	Top cap	View product →
15000527	3	Csk hd Posidriv screw M5 × 12 mm long	Ask us to source it →
15000457	4	Crown	Ask us to source it →
15000453	5A	Drum – chrome	Ask us to source it →
15000454	5B	Drum – alloy	Ask us to source it →
15000662	5C	Drum – bronze	Ask us to source it →
15000829	6	Spindle	Ask us to source it →
15008007	7	Roller bearing	Ask us to source it →
15000466	8	Drum washer	View product →
15000377	9	Main spindle sleeve (fitted to item 18)	View product →
15000464	10	Ratchet gear	Ask us to source it →
15000461	11	Gear retainer	View product →
1260/7	12	Pawl spring	View product →
1260/8	13	Pawl	View product →
15008005	14	Key	View product →
15000463	15	Idler spindle	Ask us to source it →
15000378	16	Gear spindle sleeve	View product →
15000827	17	Idler gear	Ask us to source it →
15000450	18	Centre stem	Ask us to source it →

No. 24 two-speed winch (PDF page 6)

Part no.	Item	Description
B2075	1	Circlip	Ask us to source it →
15000478	2	Top cap	View product →
15000474	3	Crown	View product →
15000527	4	Csk hd Posidriv screw M5 × 12 mm long	Ask us to source it →
15000471	5A	Drum – chrome	Ask us to source it →
15000472	5B	Drum – alloy	Ask us to source it →
15000663	5C	Drum – bronze	Ask us to source it →
15008007	6	Roller bearing	Ask us to source it →
15000830	8	Spindle	Ask us to source it →
15000376	9	Drum washer	View product →
15000377	10	Main spindle sleeve (fitted to item 11)	View product →
15000473	11	Centre stem	Ask us to source it →
1260/7	12	Pawl spring	View product →
1260/8	13	Pawl	View product →
15000423	14	Gear spindle	Ask us to source it →
15000378	15	Gear spindle sleeve	View product →
15008005	16	Key	View product →
15000477	17	Pawl gear	Ask us to source it →
15000476	18	Ratchet gear	Ask us to source it →

No. 30 two-speed winch (PDF page 6)

Part no.	Item	Description
B2075	1	Circlip	Ask us to source it →
15000433	2	Top cap	View product →
15000374	3	Crown	Ask us to source it →
15000527	4	Csk hd Posidriv screw M5 × 12 mm long	Ask us to source it →
15000448	5A	Drum – chrome	Ask us to source it →
15000447	5B	Drum – alloy	Ask us to source it →
15000664	5C	Drum – bronze	Ask us to source it →
15008007	6	Roller bearing	Ask us to source it →
15000830	8	Spindle	Ask us to source it →
15000466	9	Drum washer	View product →
15000377	10	Main spindle sleeve (fitted to item 11)	View product →
15000467	11	Centre stem	Ask us to source it →
1260/7	12	Pawl spring	View product →
1260/8	13	Pawl	View product →
15000385	14	Gear spindle	Ask us to source it →
15000378	15	Gear spindle sleeve	View product →
15008005	16	Key	View product →
15000470	17	Pawl gear	View product →
15000469	18	Ratchet gear	Ask us to source it →

No. 40 two-speed winch (PDF page 6)

Part no.	Item	Description
B2075	1	Circlip	Ask us to source it →
15000433	2	Top cap	View product →
15000495	3	Crown	Ask us to source it →
15000527	4	Csk hd Posidriv screw M5 × 12 mm long	Ask us to source it →
15000492	5A	Drum – chrome (same number as 5B, as printed)	Ask us to source it →
15000492	5B	Drum – alloy (as printed)	Ask us to source it →
15000665	5C	Drum – bronze	Ask us to source it →
15008007	6	Roller bearing	Ask us to source it →
15000491	7	Spacer (No. 40 only)	View product →
15000831	8	Spindle	Ask us to source it →
15000466	9	Drum washer	View product →
15000377	10	Main spindle sleeve (fitted to item 11)	View product →
15000494	11	Centre stem	Ask us to source it →
1260/7	12	Pawl spring	View product →
1260/8	13	Pawl	View product →
15000486	14	Gear spindle	Ask us to source it →
15000378	15	Gear spindle sleeve	View product →
15008005	16	Key	View product →
15000490	17	Pawl gear	Ask us to source it →
15000496	18	Ratchet gear	View product →

No. 43 two-speed winch (PDF page 7)

Part no.	Item	Description
B2075	1	Circlip	Ask us to source it →
B0325	2	Pan hd Posidriv screw M5 × 12 mm long	View product →
15001430	3	Collet	View product →
15000410	4A	Drum – chrome	Ask us to source it →
15000411	4B	Drum – alloy	Ask us to source it →
15000666	4C	Drum – bronze	Ask us to source it →
15010008	5	Spacer	View product →
15010007	6	Roller bearing	View product →
15034638	7	Drum washer	Ask us to source it →
15000832	8	Spindle	Ask us to source it →
15000422	9	Gear spindle	Ask us to source it →
15000377	10	Main spindle sleeve (fitted to item 20)	View product →
15000398	11	Gear spindle sleeve	View product →
15000418	12	Ratchet gear	Ask us to source it →
1260/8	13	Pawl	View product →
1260/7	14	Pawl spring	View product →
15000397	15	Pawl gear	Ask us to source it →
15000433	16	Top cap	View product →
15000416	17	Crown	Ask us to source it →
15000419	18	Pawl gear	Ask us to source it →
15000417	19	Ratchet gear	Ask us to source it →
15001544	20	Centre stem	Ask us to source it →
15000684	21	Washer	Ask us to source it →

No. 46 two-speed winch (PDF page 7)

Part no.	Item	Description
B2075	1	Circlip	Ask us to source it →
B0325	2	Pan hd Posidriv screw M5 × 12 mm long	View product →
15001430	3	Collet	View product →
15000391	4A	Drum – chrome	Ask us to source it →
15000392	4B	Drum – alloy	Ask us to source it →
15000667	4C	Drum – bronze	Ask us to source it →
15010404	5	Spacer	Ask us to source it →
15044121	6	Cage assy.	Ask us to source it →
15044116	7	Drum washer	View product →
15000833	8	Spindle	Ask us to source it →
15000394	9	Gear spindle	Ask us to source it →
15000377	10	Main spindle sleeve (fitted to item 20)	View product →
15000398	11	Gear spindle sleeve	View product →
15000396	12	Ratchet gear	Ask us to source it →
1260/8	13	Pawl	View product →
1260/7	14	Spring	View product →
15000397	15	Pawl gear	Ask us to source it →
15000433	16	Top cap	View product →
15000430	17	Crown	Ask us to source it →
15000393	18	Pawl gear	Ask us to source it →
15000395	19	Ratchet gear	Ask us to source it →
15001546	20	Centre stem	Ask us to source it →
15000684	21	Washer	Ask us to source it →

No. 52 two-speed winch (PDF page 8)

Part no.	Item	Description
B2075	1	Circlip	Ask us to source it →
15000643	2	Top cap	Ask us to source it →
15000647	3	Crown	Ask us to source it →
15001430	4	Collet	View product →
15000633	5A	Drum – alloy	Ask us to source it →
18000095	5B	Drum – stainless steel	Ask us to source it →
15000653	5C	Drum – chrome	Ask us to source it →
15000654	5D	Drum – bronze	Ask us to source it →
15000645	6	Gear spindle	Ask us to source it →
15000017	7	Roller bearing	View product →
15000834	8	Spindle	Ask us to source it →
15000627	9	Ratchet gear	Ask us to source it →
1260/7	10	Pawl spring	View product →
1264/8	11	Pawl	Ask us to source it →
15000628	12	Pawl gear	Ask us to source it →
15000646	13	Flanged washer	View product →
15000019	14	Roller bearing	View product →
B2092	15	Spirolox internal ring	View product →
15000648	16	Hollow dowel	Ask us to source it →
15000634	17	Base	Ask us to source it →
B0807	18	Skt hd csk screw M10 × 30 mm long	Ask us to source it →
15000625	19	Ratchet gear	Ask us to source it →
15001548	20	Centre stem	Ask us to source it →
15000626	21	Pawl gear	Ask us to source it →
15000644	22	Drum washer	Ask us to source it →
15044121	23	Roller bearing	View product →
B0325	24	Pan hd Posidriv screw M5 × 12 mm long	View product →
15000684	25	Washer	Ask us to source it →
15000655	26	Shim	Ask us to source it →
