Samlex Converters & Reducers - Step-Up DC-DC Converter - 9-18VDC Input - 24VDC Ouput - (20 Amp) (STEP20)

Name: Samlex Converters & Reducers - Step-Up DC-DC Converter - 9-18VDC Input - 24VDC Ouput - (20 Amp) (STEP20)
Brand: Samlex America
SKU: SMX-STEP20
Price: 382.1 USD
Availability: InStock

SKU: SMX-STEP20 | Manuf. Code: STEP20

~~List Price: 477.00 USD~~

$382.10 USD

You Save $96 This Week!

Worldwide Shipping Avalailable

SIMPLE returns & exchanges

PRICE MATCH guarantee

Knowledgeable STAFF

Description

Non-isolated, switch mode design. Step up from 12VDC to 24VDC at 20 Amps DC with very low energy consumption. Small size and light weight. Protected against overload, short circuit, reverse polarity and high voltage and transient suppression on input side.

Our Part # SMX-STEP20 | Samlex America Part # STEP20

Features

Step up from 12VDC to 24VDC at 10 Amps DC.
Switch Mode design.
CE approved.
High Efficiency.
Over-current protection.
Over-voltage, Reverse Polarity protection.
6.3 mm push-on flat pin connectors.

Technical Information

Description	Imperial	Metric
Input	9-18 VDC
Output	24 VDC
Amps	20 A
Weight	4.00 lb.	1.80 kg.
Dimensions	6.00 x 3.70 x 3.60 in.	152.00 x 93.00 x 91.00 mm.
