Lifeline turnbuckles from Hayn and Sta-Lok: toggle jaw, gate eye, deck toggle and swage-to-swage ends, open and closed body, for lifeline wire from 3/32 to 1/4 in. Click here to read more.

Lifeline Turnbuckles: End Fittings, Open or Closed Body, and Wire Size

A lifeline turnbuckle is the adjuster in a lifeline run: it sets the tension of the wire and lets you adjust it later. This page holds no products itself. It leads to eight sub-collections organised by the end fittings on each side of the body, and the choice comes down to three things: the wire diameter, the fitting you are attaching to on the boat, and the thread or pin size that fits it. These are lifeline-size turnbuckles (3/32 to 1/4 in wire, plus 4.0 and 5.0 mm in the Hayn range). For shrouds and stays see the standing rigging turnbuckles.

Lifeline Turnbuckle Sub-Collections
Open Body or Closed Body

Read the body material on the listing, because it differs by series. Hayn describes its closed-body toggle jaw and swage-to-swage turnbuckles as 316 stainless steel with forged stainless T-bolt toggles and stainless locking nuts. Its open-body toggle jaw and gate eye listings describe a forged bronze body with forged stainless T-bolt toggles, a combination Hayn says keeps strength and corrosion resistance and adds a non-galling feature. Sta-Lok’s 3/16 in x 1/4 in open-body listing describes a forged bronze, chromium-plated body supplied with a lifeline stud. The Hayn listings give the open and closed length, so compare the take-up with the space between your fittings.

How to Choose
  • Wire diameter first. The Hayn and Sta-Lok titles state the wire size the turnbuckle is made for. Match it to the lifeline you have or are building.
  • Then the fitting at the boat. A toggle jaw takes a pin at a pad eye or stanchion fitting, a deck toggle takes a screw to the deck, and a gate eye suits the end where the lifeline opens and closes.
  • Then thread and pin size. The same wire is offered in more than one thread: 3/16 in wire in 1/4-28 or 5/16-24, and 1/4 in wire in 5/16-24 or 3/8-24. Check the thread, screw or pin size against the fitting you are mating with.
  • Measure before you order. Our guide How to Measure Sailboat Lifelines shows how to record wire diameter, fittings and length bearing surface to bearing surface.
The Rest of the Lifeline

A turnbuckle is one part of the run. The other parts have their own pages: gate eyes, studs, toggles, pelican hooks, hold collars, adjusters and stanchion bases and tubes. Prefer one brand? Browse Hayn lifeline turnbuckles or Sta-Lok lifeline hardware.

Frequently Asked Questions

What wire sizes do these turnbuckles fit?
The Hayn range runs from 3/32 to 1/4 in wire, with 4.0 and 5.0 mm versions, and the Sta-Lok turnbuckles on this page cover 1/8, 5/32, 3/16 and 1/4 in. The wire size is in each product title.

What is the difference between a toggle jaw, a gate eye and a deck toggle?
It is the fitting on the end that attaches to the boat. A toggle jaw takes a pin, a gate eye is an eye end used where the lifeline opens, and a deck toggle takes a screw into the deck. Most are paired with a swage end for the wire.

Open body or closed body?
They differ in body style and, in the Hayn listings, in material: stainless for the closed-body toggle jaw and swage-to-swage, forged bronze for the open-body toggle jaw and gate eye. Compare the listed open and closed lengths for the adjustment you need.

What does “w/ Handy Crimp Stud” mean?
These Hayn turnbuckles are listed with a Handy Crimp stud. Hayn states that Handy Crimp hardware is for low-load applications only and, properly installed with the Hayn Nicopress tool, develops about 70% of cable strength.

Can I use these on shrouds and stays?
These are lifeline turnbuckles sized for lifeline wire. For standing rigging use the standing rigging turnbuckles.
