Barient winches have been out of production for more than a decade, so there is no factory replacement — but every Barient model maps to a modern equivalent from Andersen, Antal, Harken, Lewmar, or Ronstan, matched by power ratio and base diameter. Find your Barient model number in the cross-reference charts below, then choose the matching size from your preferred brand. Use the plain-top chart for standard winches and the self-tailing chart for self-tailing models.
Barient replacement brands at a glance
| Brand | Typical match basis | Best for |
|---|---|---|
| Andersen | Stainless drum, power & base size | Owners wanting a stainless-steel self-tailing winch with a similar footprint |
| Antal | Power ratio & base diameter | Aluminum winches at competitive weight and price |
| Harken | Radial / performance line, power & base | Racers and performance cruisers wanting the closest power match |
| Lewmar | Ocean / EVO line, power & base size | Widely stocked, easy-to-service general-purpose replacement |
| Ronstan | Orbit self-tailing, power & base size | Smaller self-tailing sizes with QuickTrim jaws |
Are Barient winches still made?
No. Barient stopped manufacturing winches more than a decade ago, so no new units or factory-original spares are produced. Because parts are increasingly scarce, most owners replace rather than rebuild — and the cross-reference charts below let you do that without guessing. The two things that must match are the winch’s pulling power (its power ratio at each speed) and the base diameter, so the new winch bolts to the same footprint on deck.
How do I find the modern equivalent for my Barient winch?
Identify your Barient model (usually stamped on the drum or base), decide whether it is a plain-top or self-tailing winch, then read across the matching chart to the brand you prefer. If the stamp has worn away, measure the base diameter in millimeters and compare it against the base-size columns in the spec tables to pin down the closest model.
Standard — plain-top winch equivalents
| Barient | Andersen | Antal | Harken | Lewmar |
|---|---|---|---|---|
| 12 | 16 | W16.2 | B16 | 16.2 |
| 10P | 10 | W8 | B8 | 8 |
| 8P | 10 | W7 | B6 | 8 |
| 17 | 16 | W16.2 | B16 | 16.2 |
| 18 | 28 | W30.2 | — | 30 |
| 21 | 28 | W30.2 | 35.2PT | 30 |
| 22 | 40 | W42.2 | 35.2PT | 40 |
| 632 | — | — | 40.2PT | — |
| 24 | 46 | W44.2 | 40.2PT | — |
| 28+ | — | W44.2 | 46.2PT | — |
| 25 | 46 | W44.2 | 46.2PT | — |
| 27 | — | W48.2 | 46.2PT | — |
| 32 | — | W48.2 | 50.2PT | — |
Self-tailing winch equivalents
| Barient | Andersen | Antal | Harken | Lewmar | Ronstan |
|---|---|---|---|---|---|
| 17ST | 18ST | — | 15ST | 16ST | 20ST |
| 21ST | 30ST | XT30.2 | — | 30ST | 30QT |
| 22ST | 40ST | XT40 | 40.2ST | 40ST | 40QT |
| 24ST | 46ST | XT44 | 46.2ST | 46ST | — |
| 27ST | 50ST | XT48 | 46.2ST | 48ST | — |
| 28+ST | 52ST | XT52 | 50.2ST | 50ST | — |
| 32ST | 62ST | XT66 | 70.2ST | 65ST | — |
| 32-3ST | — | XT66.3 | 70.3ST | — | — |
| 736ST | 68ST | XT66 | 70.2ST | 65ST | — |
| 736-3ST | — | XT66.3 | 70.3ST | — | — |
| 36ST | 68ST | XT66 | 70.2ST | 65ST | — |
| 36-3ST | — | XT66.3 | 70.3ST | — | — |
| 737ST | 72ST | XT70 | 70.2ST | — | — |
| 737-3ST | 82-3ST | XT70.3 | 70.3ST | — | — |
| 37ST | 82-3ST | — | 80.2ST | — | — |
| 37-3ST | 82-3ST | — | 80.3ST | — | — |
What is the difference between plain-top and self-tailing models?
A self-tailing winch has a spring-loaded jaw on top of the drum that grips the line, so it can be tailed hands-free by one person. A plain-top (standard) winch has no jaw and needs a separate cleat or a second crew member to hold the tail. Match your Barient to the chart for its own type — a plain-top Barient can be replaced with a self-tailing modern winch, but not the other way around without losing the self-tailing function.
Which brand should I choose?
Any of the five brands will work if the power and base size match, so the choice usually comes down to material, servicing, and budget. Andersen offers stainless drums; Antal is a lighter-weight aluminum option; Harken and Lewmar are the most widely stocked and easiest to service in most markets; Ronstan Orbit self-tailers cover the smaller sizes with QuickTrim jaws. When two equivalents are listed, pick the one whose base diameter is closest to your original Barient so the new winch reuses the same bolt pattern.
Frequently asked questions
Are Barient winches still made?
No. Barient stopped manufacturing winches more than a decade ago, so no new units or factory replacements are produced. Owners replace them with equivalent models from Andersen, Antal, Harken, Lewmar, or Ronstan using a cross-reference chart matched by power and base size.
What modern winch replaces a Barient winch?
Find your Barient model in the cross-reference chart and select the matching size from your preferred brand. Each Barient model maps to an Andersen, Antal, Harken, Lewmar, or Ronstan equivalent chosen so the power ratio and base diameter are as close as possible to the original.
How do I identify my Barient winch model and size?
The model number is usually stamped on the winch drum or base. If it has worn away, measure the base diameter in millimeters and compare it against the base-size columns in the spec tables to identify the closest model.
What is the difference between plain-top and self-tailing Barient winches?
A self-tailing winch has a jaw on top that grips the line so it can be tailed hands-free; a plain-top (standard) winch has no jaw and requires a separate cleat or a second crew member to hold the line. Match your winch to the chart for its type.
Can I still get parts or service for Barient winches?
Spare parts are increasingly scarce because Barient has been out of production for years, so many owners choose to replace rather than rebuild. MAURIPRO’s specialists can identify the right modern equivalent for your model and footprint.
