Lewmar Winch Service Manual — Volume 6

This manual is split into 4 pages: Part 1 · Part 2 → · Part 3 → · Part 4 →

Service Routine

  • Monthly: hose down with fresh water, then lightly oil and grease.
  • Two or three times in the active season: stop, clean and re-lubricate.
  • End of season or before the new one: strip completely, clean, check for damage, lubricate and reassemble.
  • Assemble in the reverse sequence to dismantling.
  • Grease: Lewmar Grease 7010 (Lubriplate Marine Lube 'A', etc). Oil: light machine oil (3-in-1 or equivalent).

Mounting

  • Use the correct size and type of retaining bolts.
  • Remove the drum to mount the winch, on a flat, clean surface.
  • Mark off and drill each bolt hole separately.
  • Bed on a LIGHT coat of sealing compound: too much gets into the gears and pawls.
  • Tighten the fastenings securely but do not over-tighten, and keep the drain holes clear.
  • All current winches accept any standard international handle.

Spares Kits Listed in the Manual

Ref. Description
7001 Basic winch servicing kit (4 circlips, pawls, pawl springs)
7002 Winch servicing kit 4 (4 circlips, 8 pawls, 12 pawl springs, 3 keys, 2 pan head screws – self tailors)
7003 Three speed winch servicing kit
7009 Allen key set
7010 Grease, 100 g plastic tube
7011 Grease, 300 g plastic tub
7012 Assembly paste, 300 g tub
7013 Naval Jelly, 200 ml jar (removes staining from stainless steel and passivates it)

Part numbers in the lists below are copied from the 1991 manual. Where a number matches a part we stock today we link it; anything else, ask us and we will check the current replacement.

Single-Speed & Halyard Winch Parts

No. 6 single-speed winch (PDF page 3)

Part no. Item Description
B2075 1 Circlip Ask us to source it →
15000388 2A Top cap – alloy drum Ask us to source it →
18000048 2B Top cap – chrome & bronze drum Ask us to source it →
1260/7 3 Pawl spring View product →
1260/8 4 Pawl View product →
15000148 5 Spindle Ask us to source it →
15006102 6A Drum – chrome Ask us to source it →
15000363 6B Drum – alloy Ask us to source it →
15000660 6C Drum – bronze Ask us to source it →
15006004 7 Washer Ask us to source it →
15006005 8 Key View product →
15000144 9 Centre stem Ask us to source it →

No. 7 single-speed winch (PDF page 3)

Part no. Item Description
B2075 1 Circlip Ask us to source it →
15000443 2A Top cap – alloy drum Ask us to source it →
15000478 2B Top cap – chrome & bronze drum View product →
1260/7 3 Pawl spring View product →
1260/8 4 Pawl View product →
15000148 5 Spindle Ask us to source it →
15000650 6A Drum – chrome Ask us to source it →
15000364 6B Drum – alloy Ask us to source it →
15000661 6C Drum – bronze View product →
15006004 7 Washer Ask us to source it →
15010005 8 Key View product →
15000143 9 Centre stem Ask us to source it →
15000652 10 Crown Ask us to source it →
15000527 11 Screw Ask us to source it →

No. 8 single-speed winch (PDF page 4)

Part no. Item Description
15008003 1 Spindle View product →
15008004 2 Drum washer View product →
15008007 3 Roller bearing Ask us to source it →
15008001 4 Centre stem Ask us to source it →
15008005 5 Key View product →
1260/7 6 Pawl spring View product →
1260/8 7 Pawl View product →
15000650 8A Drum – chrome Ask us to source it →
15000364 8B Drum – alloy Ask us to source it →
15000661 8C Drum – bronze View product →
15000434 9A Top cap – alloy Ask us to source it →
15000478 9B Top cap – chrome & bronze drum View product →
B2075 10 Circlip Ask us to source it →
15000651 11 Crown Ask us to source it →
15000527 12 Screw Ask us to source it →

No. 1 halyard reel winch (PDF page 15)

Part no. Item Description
B2075 1 Circlip Ask us to source it →
18000047 2 Top cap Ask us to source it →
1260/8 3 Pawl View product →
1260/7 4 Pawl spring View product →
15001022 5 Drum Ask us to source it →
15008003 6 Spindle View product →
15008007 7 Roller bearing Ask us to source it →
15001024 8 Ratchet ring Ask us to source it →
15001025 9 Brake strap Ask us to source it →
15001021 10 Centre stem Ask us to source it →
15001008 11 Locating pin Ask us to source it →
15008005 12 Key View product →
15001010 13A Brake lever Ask us to source it →
15001011 13B Brake screw Ask us to source it →
15001009 13C Handle rivet Ask us to source it →
15001006 14 Guard rod Ask us to source it →
B0901 15 Grub screw Ask us to source it →
B1992 16 Halyard plate Ask us to source it →

Need a part that isn't listed? Ask us to source it and quote the part number from the PDF.
