Facnor Spare Parts Model SD & R - Selection Guide

Profurl Furler - C320 Cruising Unit - Boat Size: Up to 36.0 ft (11.0 m)

To order the right Facnor SD or R furler spare part, match your furler model (e.g. SD130 or R200) to the item number in the compatibility tables below, then use the listed part number. Facnor's SD line covers eleven sizes (SD060 through SD290) and the R line covers eight sizes (R080 through R300), and many components are shared across several sizes, so identifying your exact model first prevents ordering the wrong part.

Facnor SD & R spare parts at a glance

Furler line Models covered Typical serviceable parts
SD (heavy-duty headsail furler) SD060, SD070, SD080, SD100, SD130, SD150, SD165, SD180, SD200, SD260, SD290 Drum halves, sail feeder, bottom extrusion screws, tack swivel components
R (racing/performance furler) R080, R100, R130, R150, R200, R260, R290, R300 Drum halves, torque tube parts, extrusion connectors, sail feeder, halyard swivel parts

How do I identify my Facnor SD or R furler model?

Your furler size is printed on the unit and appears in its original documentation as an SD or R code followed by three digits (for example SD130 or R200). The digits correspond roughly to the maximum forestay/luff wire diameter the unit is rated for, which is why parts are grouped by model. Confirm your exact model before ordering, because a component that fits an SD100 will not necessarily fit an SD200.

Facnor Bottom Extrusion Telescopic Section for FD170 / LS070 / LS130 / LX100 / LX130 Furlers
Facnor bottom extrusion telescopic sections are matched to specific furler size groups — always confirm your model before ordering an extrusion part.

Which spare parts are available for the SD models?

The table below lists every stocked SD spare part by item number and model. Each linked part number opens the product on our site; the manufacturer code is shown alongside so you can cross-check against Facnor documentation. A dash means that item is not used on that model, and items marked as unavailable can still be sourced through our team.

#Item Models
SD060 SD070 SD080 SD100 SD130 SD150 SD165 SD180 SD200 SD260 SD290
Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code
1 FAC0098 9171000205 FAC0098 9171000205 FAC0098 9171000205 FAC0098 9171000205 FAC0098 9171000205 FAC0100 9171000306 FAC0100 9171000306 FAC0100 9171000306 FAC0102 9171000508 FAC0102 9171000508 FAC0102 9171000508
1 FAC0099 9171000206 FAC0099 9171000206 FAC0099 9171000206 FAC0099 9171000206 FAC0099 9171000206 FAC0101 9171000310 FAC0101 9171000310 FAC0101 9171000310 FAC0103 9171000509 FAC0103 9171000509 FAC0103 9171000509
1

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

 FAC2161 9171000512 FAC2161 9171000512 FAC2161 9171000512
1

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

 FAC0104 9171000514 FAC0104 9171000514 FAC0104 9171000514
5 FAC3289 9130124140 FAC3289 9130124140 FAC3289 9130124140 FAC3289 9130124140 FAC3289 9130124140 FAC0047 9130124150 FAC0047 9130124150 FAC0047 9130124150 FAC0047 9130124150 FAC0047 9130124150 FAC0047 9130124150
11 FAC2211 31001250600 FAC2211 31001250600 FAC2211 31001250600 FAC2211 31001250600 FAC2211 31001250600 FAC2211 31001250600 FAC2211 31001250600 FAC2212 31001250800 FAC2212 31001250800 FAC2212 31001250800 FAC2212 31001250800
16 FAC2210 31001250500 FAC2210 31001250500 FAC2210 31001250500 FAC2210 31001250500 FAC2210 31001250500 FAC2211 31001250600 FAC2211 31001250600 FAC2211 31001250600 FAC2212 31001250800 FAC2212 31001250800 FAC2212 31001250800
Facnor Bottom Extrusion Screws (32 pack) for FD210 / FD280 / FD310 / LS165 / LS200 / LS290 / LX165 / LX180 / LX200 / LX290 / RX300 Furlers
Facnor bottom extrusion screw packs secure the foil sections on larger SD and R furlers — a common wear item during a rebuild.

Which spare parts are available for the R models?

The R-model table covers the racing/performance range from R080 to R300, including torque-tube, extrusion-connector, drum and swivel components. As with the SD table, dashes indicate the part does not apply to that model, and each active part number links directly to the item.

#Item Models
R080 R100 R130 R150 R200 R260 R290 R300
Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code Part Num. Mfr. Code
1 FAC0098 9171000205 FAC0098 9171000205 FAC0098 9171000205 FAC0100 9171000306 FAC0100 9171000306 FAC0102 9171000508 FAC0102 9171000508 FAC0102 9171000508
1 FAC0099 9171000206 FAC0099 9171000206 FAC0099 9171000206 FAC0101 9171000310 FAC0101 9171000310 FAC0103 9171000509 FAC0103 9171000509 FAC0103 9171000509
1

-

-

-

-

-

-

-

-

-

-

 FAC2161 9171000512 FAC2161 9171000512 FAC2161 9171000512
1

-

-

-

-

-

-

-

-

-

-

 FAC0104 9171000514 FAC0104 9171000514 FAC0104 9171000514
2 FAC0270 9130204140 FAC0270 9130204140 FAC0270 9130204140 FAC0270 9130204140 FAC0270 9130204140 FAC0270 9130204140 FAC0270 9130204140 FAC0270 9130204140
3 FAC3160 9190014041 FAC3160 9190014041 FAC3160 9190014041

-

9190024040

-

9190024040

-

9190024040

-

9190024040

-

9190024040
4 FAC3049 9170014040 FAC3049 9170014040 FAC3049 9170014040 FAC3038 9170024040 FAC3038 9170024040 FAC3014 9170034040 FAC3014 9170034040 FAC3014 9170034040
5 FAC3296 9130124320 FAC3296 9130124320 FAC3296 9130124320 FAC3296 9130124320 FAC3296 9130124320 FAC0047 9130124150 FAC0047 9130124150 FAC0047 9130124150
7 FAC2013 26097014030 FAC2013 26097014030 FAC2013 26097014030 FAC2017 26097024030 FAC2017 26097024030 FAC2014 26097034030 FAC2014 26097034030 FAC2014 26097034030
8 FAC3160 9190014041 FAC3160 9190014041 FAC3160 9190014041 FAC2203 9190124040 FAC2203 9190124040 FAC2205 9190134040 FAC2205 9190134040 FAC2205 9190134040
8 FAC2202 9190114040 FAC2202 9190114040 FAC2202 9190114040

-

9190024040

-

9190024040

 FAC3158 9190134041 FAC3158 9190134041 FAC3158 9190134041
8 FAC3219 9190114041 FAC3219 9190114041 FAC3219 9190114041

-

-

-

-

-

-

-

-

-

-
9 FAC0032 9130128140 FAC0032 9130128140 FAC0032 9130128140 FAC0033 9130128240 FAC0033 9130128240 FAC0035 9130128340 FAC0035 9130128340 FAC0035 9130128340
9 FAC0145 9130128142 FAC0145 9130128142 FAC0145 9130128142 FAC2234 9130128242 FAC2234 9130128242

-

-

-

-

-

-
Facnor Sail Feeder Assembly (Standard) for FD110 / RX070 / RX100 / RX130 / RX165 Furlers
A Facnor sail feeder assembly guides the luff tape into the foil groove and is one of the most frequently replaced furler service parts.

What if my part shows as unavailable or I can't find it?

Some low-demand components are marked as unavailable to order online, but Facnor spares can usually still be obtained on request. If a part number links to a "contact us" page, or you are unsure which item you need, reach out to our rigging team with your furler model and we will confirm the correct part.

Frequently asked questions

How do I know which Facnor SD or R spare part I need?

Find your furler model code (such as SD150 or R130), then read across that model's column in the tables above to the item you're replacing. The linked part number is the correct component for that model.

Are SD and R furler parts interchangeable?

Some components are shared between certain SD and R sizes and even across models, but many are size-specific. Always verify by model and item number rather than assuming a part carries over.

What does a dash (-) mean in the parts table?

A dash indicates that item number does not apply to that particular furler model, so no part is required or offered in that position.

What is the manufacturer code column for?

It is Facnor's own reference number for each component, provided so you can cross-check the part against Facnor's official documentation or a quote.

Can I still get a part listed as unavailable?

Yes. Parts flagged as unavailable online can often be special-ordered — contact our rigging team with your furler model and the item number and we will source it.

Where do I find replacement extrusions and screws for my furler?

Bottom extrusion telescopic sections and screw packs are listed by compatible model in the tables and are also available in our Facnor collection linked below.
